1. Technical Specifications

• Model: Motorola IPMC761-001
• Type: VMEbus Peripheral Board
• Processor: Typically integrated with a microcontroller or microprocessor, though the specific details should be confirmed from the datasheet or product documentation.
• Memory:
  • RAM: Onboard RAM, size and configuration details are specified in the datasheet.
  • Flash/ROM: May include onboard flash or ROM for firmware storage.
• I/O Interfaces:
  • Serial Ports: Multiple serial communication interfaces (e.g., RS-232/RS-422).
  • Parallel I/O: Configurable parallel I/O ports.
  • Digital and Analog Inputs/Outputs: May include a range of digital and analog I/O options for interfacing with various sensors and actuators.
• Bus Interface: Compliant with the VMEbus standard, facilitating integration into VME-based systems.
• Power Requirements: Typically operates within standard VMEbus power specifications. Exact power requirements should be checked in the datasheet.

2. Key Features

• VMEbus Compliance: Fully compliant with the VMEbus standard, ensuring compatibility with VME-based systems and chassis.
• Flexible I/O Options: Provides a wide range of I/O options to interface with external devices, sensors, and actuators.
• High Reliability: Designed for reliable performance in demanding environments, with robust construction to withstand industrial conditions.
• Expandable: May support additional expansion options for increased functionality, depending on the specific configuration.

3. Application Scenarios

• Industrial Automation: Ideal for use in industrial control systems where flexibility and reliability are essential for controlling machinery and processing data.
• Embedded Systems: Suitable for integration into embedded systems that require VMEbus compatibility and extensive I/O capabilities.
• Defense and Aerospace: Used in defense and aerospace applications due to its high reliability and ability to interface with a variety of sensors and control systems.
• Data Acquisition: Applied in data acquisition systems where high-performance I/O and processing capabilities are needed for accurate data collection and analysis.

4. Additional Information

• Installation and Maintenance: Requires installation into a VMEbus chassis, with proper configuration to ensure compatibility with other system components. Regular maintenance involves ensuring the board remains within operational parameters and performs system checks.
• Technical Support: Detailed technical support is available from Motorola or authorized distributors. For specific installation guidance, troubleshooting, or technical queries, consult the official product datasheet or contact Motorola directly.
