Manufacturer:Mitsubishi Electric

Product Model:QM100HY-H

Module Type:Digital Input Output Module

Input Channels:32 channels

Output Channels:32 channels

Input Voltage Range:DC24V

Output Voltage Range:DC24V

Current Rating per Channel:0.5A

Communication Interface:CC-Link, CC-Link IE Field Basic

Operating Temperature Range:-15°C to +65°C

Protection Rating:IP66

Weight:Approx. 1kg

Dimensions (W x D x H):140mm x 120mm x 100mm

    The MITSUBISHI QM100HY-H is a high-performance data acquisition module designed to meet the demands of modern industrial automation. This module features 32 input channels capable of sampling at speeds up to 100 kHz, providing unparalleled precision and responsiveness. With a resolution of 12 bits, it ensures accurate and reliable data collection. The module operates on a 24 VDC power supply, making it easy to integrate into existing systems. Designed for harsh industrial environments, the QM100HY-H can operate within a temperature range of -10°C to +60°C and maintains functionality in humidity levels up to 90% RH. Its compact dimensions of 112 mm x 100 mm x 70 mm make it ideal for space-constrained installations. The module also meets stringent safety and quality standards, including CE, UL, and RoHS certifications. Whether you’re monitoring critical processes or integrating into complex control systems, the MITSUBISHI QM100HY-H delivers superior performance and reliability.
