MITSUBISHI QM100DY-H Q Series Digital Input Module for Industrial Automation
The MITSUBISHI QM100DY-H is an advanced digital input/output module designed for industrial automation systems. It offers exceptional compactness and uniform design, ensuring quick and efficient installation. With its safe torque-off function (SIL3) and sensorless vector control, it is ideal for a wide range of applications including textile, printing, rubber and plastics, and woodworking.
Detailed content
Manufacturer:Mitsubishi Electric
Model:QM100DY-H
Series:MELSEC-Q
Module Type:Digital Input/Output
Input Points:16 points
Output Points:16 points
Voltage Rating:DC 24V
Current Rating:0.5A per point
Communication Interfaces:RS-485, Ethernet
Operating Temperature Range:-10°C to +60°C
Humidity Range:5% to 95% (non-condensing)
Power Consumption:2.2W
Dimensions:112mm x 95mm x 75mm (W x H x D)
Weight:0.2kg
Certifications:CE, UL, CSA
The MITSUBISHI QM100DY-H Digital Input/Output Module stands out for its exceptionally compact design and uniform look, making it perfect for space-constrained applications. Quick commissioning is facilitated by application macros and panel assistants, reducing setup time significantly. The module comes equipped with a safe torque off function (SIL3) as standard, ensuring safe operation in critical applications. It supports sensorless vector control for induction motors and permanent magnet motors up to 599 Hz, offering versatile motor control options. Additionally, the built-in braking chopper and coated boards enhance reliability and durability, especially in harsh environments. The IP66 variant is available for applications requiring high protection against dust and water ingress. This module is an excellent choice for industrial automation projects looking for reliable and efficient digital input/output solutions.
