Design:4-axis

Communication Protocol:SSCNET

Connection Type:RJ45 Connector

Mounting Mode:Backplane/Rack

Operating Voltage:DC 24V

Current Consumption:≤1.2A

Operating Temperature:-10°C to +60°C

Dimensions (WxDxH):110mm x 90mm x 100mm

Weight:0.5kg

    The Mitsubishi QD75MH2 Precision Motion Control Positioning Unit is engineered for high-precision applications in manufacturing and automation industries. Its compact design and robust performance make it suitable for a wide range of tasks, from simple positioning to complex robotic operations.

    Featuring a high-resolution encoder and a proprietary control algorithm, this unit ensures smooth and precise movements, minimizing overshoots and reducing positioning errors. Its SSCNET communication interface allows seamless integration with Mitsubishi PLCs and other compatible systems, facilitating easy setup and operation.

    Manufactured with a conformal coating for chemical resistance, the QD75MH2 is built to withstand harsh industrial environments. It supports up to four axes, enabling versatile applications in machinery, assembly lines, and testing equipment.

    For enhanced reliability and safety, the unit includes overcurrent protection and fault detection mechanisms, ensuring uninterrupted operation even under challenging conditions. Its low power consumption contributes to energy efficiency and cost savings over its operational lifetime.

    Designed with user-friendliness in mind, the Mitsubishi QD75MH2 comes with comprehensive documentation and support resources, making it accessible to both experienced engineers and newcomers to the field of industrial automation.
