Technical Specifications:

• Type: Universal Transducer Module
• Model Number: MUTDOA13 (51304648-100)
• Function: Provides signal conversion and interfacing for various types of field devices in control systems.
• Input Types: Supports multiple types of inputs, including:
  • Analog Inputs: Measures signals such as 0-10V, 4-20mA, etc.
  • Digital Inputs: Accepts digital signals for discrete on/off status.
• Output Types:
  • Analog Outputs: Provides output signals for control purposes.
  • Digital Outputs: Used for control signals or status indications.
• Communication Protocols: Interfaces with Honeywell’s control systems, typically supporting industry-standard communication protocols (specific protocols should be verified in the datasheet).
• Power Supply: Operates generally on 24V DC; exact power requirements should be confirmed in the datasheet.
• Temperature Range: Designed for industrial environments, operating typically within -10°C to 60°C.
• Mounting: Designed for DIN rail or panel mounting depending on the installation requirements.

Features:

• Versatile Input/Output: Offers versatile input and output options for interfacing with various field devices, making it adaptable to different system needs.
• High Accuracy: Ensures accurate signal measurement and control, which is critical for reliable system performance.
• Modular Integration: Part of a modular control system, facilitating easy integration and expansion.
• User-Friendly Configuration: Includes configuration tools for straightforward setup and diagnostics.
• Built-In Diagnostics: Equipped with diagnostic features to assist with troubleshooting and system maintenance.

Applications:

• Industrial Automation: Used to interface and control various field devices in industrial automation systems, ensuring proper signal conversion and system integration.
• Manufacturing: Applied in manufacturing environments for monitoring and controlling processes through various input and output signals.
• Building Automation: Integrates into building management systems for controlling HVAC, lighting, and other systems based on various signal inputs.
• Energy Management: Used in energy management systems to interface with devices for monitoring and controlling energy consumption.
