Technical Specifications
Processor: Utilizes an Intel Pentium III processor with a clock speed up to 1.26 GHz, featuring a 512 Kbyte (or 1.26 GHz variant with 512 Kbyte) Advanced Transfer Cache (ATC) for enhanced performance.
Memory: Accepts a 144-pin SDRAM SODIMM, supporting up to 512 Mbyte of PC133 SDRAM.
Graphics: Integrated AGP graphics adapter based on the Intel 815E chipset, supporting resolutions up to 1600 x 1200 pixels with 256 colors (single-view mode) and complemented by 4 Mbyte of external synchronous DRAM cache.
I/O Interfaces: Provides various I/O interfaces including GPIO, serial ports, and dual Ethernet controllers supporting 10BaseT and 100BaseTX.
Communication: Supports high-speed communication protocols such as Gigabit Ethernet and PCI Express, ensuring reliable data transmission.
Expansion: Offers slots and interfaces for easy expansion of other functional modules, meeting different application requirements.
Functional Characteristics
High-Performance Computing: The Pentium III processor, with its 32-bit addressing and 64-bit data bus, delivers powerful computing capabilities and efficient task handling.
Advanced Graphics Support: The AGP graphics adapter supports high-resolution graphics and multimedia quality video, making it suitable for applications requiring advanced visual display.
Ethernet Connectivity: Dual Ethernet controllers enable seamless integration into local area networks (LANs), supporting remote boot capabilities through Lanworks Technologies’ BootWare.
Flexible Configuration: Supports configurable input and output ranges, allowing users to tailor the module to specific application needs.
High-Precision Clock and Trigger: Equipped with high-precision clock and trigger functions, enabling synchronized and precise data acquisition and output.
Application Scenarios
Industrial Automation: Ideal for controlling and monitoring industrial processes, automation lines, and manufacturing equipment.
Data Acquisition: Suitable for applications requiring high-speed data acquisition and processing, such as scientific research, testing, and measurement systems.
Embedded Systems: Can serve as a core processing module in embedded systems, providing a flexible and reliable platform for complex control logic and data processing tasks.
Military Electronics: Due to its high performance and reliability, the VMIVME-7750 is also suitable for military-grade electronics and systems.
