Dimensions: Approximately 200x156x90mm³, with a net weight of 1.6kg.
Power Supply Protection: Includes features such as overheat protection, overcurrent protection, and undervoltage protection.
Phase Memory Function: Automatically remembers the phase position when input pulses stop for more than 5 seconds.
Communication Interfaces: Potentially supports Modbus/TCP, TCP/IP, UDP, DHCP, Bootp, SNMP, HTTP, and SNTP protocols for data exchange and remote monitoring.
Functional Features
High Performance: Incorporates a servo-like control principle that ensures smooth low-speed operation with minimal vibration and noise.
High Speed and Precision: Enables high-speed operation with significantly higher torque compared to two-phase and five-phase hybrid stepping motors.
Adjustable Drive Current: Provides 16-step adjustable drive current for fine-tuning motor performance.
Optical Isolation: Incorporates optical isolation for signal inputs and outputs, enhancing system stability and reducing interference.
Protection Circuits: Equipped with overvoltage, overcurrent, and overtemperature protection circuits to safeguard the motor and drive system.
Dual-Polarity Constant Current Chopper: Enables the same motor to output higher speeds and powers.
Application Scenarios
Automation Equipment: Widely used in automation equipment requiring high speed, precision, and smooth operation, such as woodworking engraving machines, CNC machines, ceramic equipment, packaging machines, electronic devices, water drilling equipment, glass machinery, computer embroidery machines, and laser cutting machines.
Industrial Machinery: Ideal for industrial machinery applications where high-performance stepping motor control is essential.
Precision Positioning: Utilized in applications requiring precise positioning and high-resolution control, such as automation assembly lines, material handling systems, and precision measurement devices.
