GE SR745-W3-P5-G5-HI – Transformer Management Relay with Advanced Features
The GE Multilin 745-W3-P5-G5-HI Transformer Management Relay is designed to protect and manage power transformers ranging from small to large. It provides enhanced control power and features an advanced 40-character display with an expanded keypad for easier setpoint entry.
Detailed content
Weight:4.8kg
Voltage Input Burden:Less than 0.025 VA at 120 V
Source VT:2 to 600 kV / 60 to 120 V
Number of Logic Inputs:16
Fuse Current Rating:3.15 A
Display:Enhanced 40 Character LCD
Operating Temperature Range:-40°C to +60°C
Dimensions:9 inches H, 7 ⅛ inches D, 7 inches W
IRIG-B Input Impedance:70 to 100 kΩ
Input Voltage:60 to 120V
The GE SR745-W3-P5-G5-HI is an essential component for managing and protecting transformers in industrial settings. With its enhanced 40-character display and a comprehensive set of logic inputs, it ensures precise monitoring and control. The robust design allows it to function independently or integrate seamlessly with other relays in the GE Multilin 745 series.
The unit is equipped with advanced protection features, including a transformer protection system that can be mounted on a standard 19” panel. Its user-friendly interface includes a number of LEDs that provide real-time alerts for various statuses and errors.
Designed for reliability and ease of use, the GE SR745-W3-P5-G5-HI is built to withstand harsh industrial environments, with an operating temperature range of -40°C to +60°C. This makes it suitable for applications in diverse industries, from manufacturing to utility companies.
Furthermore, the device supports passcode protection and a clock display, enhancing security and operational efficiency. With its high control power and extensive adaptive capabilities, this relay is a valuable asset for any industrial control system.
