Technical Specifications

• Model: IS420UCSBH1A
• Brand: General Electric (GE)
• Series: Quantum Series
• Interface: Ethernet
• Protocol: Modbus TCP/IP
• Transmission Rate: 10/100 Mbps
• Connection Capacity: Up to 8 connections
• Operating Temperature: -25°C to +55°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5% to 95% (non-condensing)
• Dimensions: 115 mm x 45 mm x 23 mm
• Weight: 0.2 kg (as per some sources, while other sources mention 2.4 pounds, which is likely for a different model or configuration)

Functional Characteristics

• Data Collection: The IS420UCSBH1A module collects data from various sensors, instruments, and monitoring equipment, including analog and digital signals.
• Signal Processing: It processes the collected data through functions such as filtering, amplification, digitization, and calibration to ensure data accuracy and reliability.
• Communication Interface: Equipped with Ethernet and possibly other communication interfaces (e.g., RS-232, RS-485), enabling data communication with other devices and monitoring systems.
• Data Recording and Storage: Supports data recording and storage functions, allowing the stored data to be analyzed and reported for future use.
• Real-Time Monitoring: Monitors the status of equipment and systems in real-time, as well as key parameters, enabling timely identification of abnormal situations or faults.
• Remote Access: May include remote access functionality, allowing users to remotely monitor and control devices.
• Alarm and Notification: Sets alarm conditions to generate notifications when abnormal situations are detected.
• Modular Design: Allows for expansion and customization of functions to adapt to different monitoring and control tasks.
• High Reliability: Designed with high-quality components and a reliable architecture to ensure stable operation in industrial environments.

Application Scenarios

• Industrial Automation: Used in various industrial automation applications, such as production line control, machine control, and process control.
• Process Control: Monitors and controls industrial processes like chemical production, petroleum refining, and water treatment, ensuring process stability and consistency.
• Data Collection and Monitoring: Collects and monitors data from sensors, facilitating analysis and reporting for better decision-making.
• Energy Management: Monitors energy usage (e.g., electricity, water, gas) to optimize consumption and reduce operating costs.
• Environmental Monitoring: Used in monitoring air quality, temperature, humidity, and other environmental parameters, ensuring environmental safety and compliance.
• Manufacturing: Controls production equipment, coordinates production processes, and ensures product quality in manufacturing industries.
