Technical Specifications

• Model Number: IS215WEPAH2BA
• Manufacturer: GE Aviation
• Type: Single-Phase AC Solid-State Relay
• Rated Current: 15A
• Rated Voltage: 28V AC
• Control Voltage: 5V DC
• Switching Frequency: 200Hz
• Transient Surge Current Capacity: 100A
• Insulation Resistance: >1000MΩ
• Operating Temperature Range: -55°C to 125°C
• Housing Material: Metal
• Mounting Type: PCB Installation
• Compliance: MIL-STD-810, MIL-STD-202, DO-160, and other aerospace standards

Functional Characteristics

1. High Reliability:
   • Built with high-quality components and rigorous manufacturing processes, providing excellent reliability for aerospace applications.
   • Undergoes stringent testing and screening to meet the demanding requirements of aerospace environments.
2. High Performance:
   • Fast switching speeds enable precise control and response to input signals.
   • High insulation strength ensures resistance to high voltage spikes and transients.
   • Strong vibration resistance withstands the rigors of aerospace operations.
3. Compact Design:
   • Small size and lightweight design save valuable space in space-constrained aerospace systems.
   • Ease of installation on PCBs, facilitating integration into various aerospace equipment.
4. Low Power Consumption:
   • Low power requirements improve overall system efficiency and reduce heat generation.
   • Suitable for use in power-sensitive aerospace applications.
5. Multiple Approvals and Compliance:
   • Compliant with MIL-STD-810, MIL-STD-202, DO-160, and other aerospace standards, ensuring product quality and reliability.
6. Long Lifespan:
   • High-quality components and robust design contribute to a long service life, reducing maintenance costs and downtime.
7. Ease of Use:
   • Does not require additional drive circuits, simplifying integration and use.

Application Scenarios

GE IS215WEPAH2BA solid-state relay is ideally suited for various aerospace applications, including:

• Avionics Systems: Utilized in aircraft avionics systems for precise control and monitoring of electrical systems.
• Engine Control Systems: Involved in engine control, ensuring reliable operation and performance.
• Flight Control Systems: Plays a critical role in flight control systems, providing reliable switching and control functions.
• Power Distribution Systems: Used in power distribution systems to distribute and control electrical power throughout the aircraft.
