Product Type:Termination Board

Series:Mark VI

Functional Revision:C

Artwork Revision:B

Mounting Configuration:Conformally Coated PCB

Input Capacity:Two Servo Current Sources

Board Size:Dimensions: 11 x 6 x 6.7 cm

Weight:1.21 kg

    Crafted specifically for the demanding requirements of industrial gas and steam turbine systems, the GE IS200TSVOH1BCC terminal board ensures unparalleled performance and reliability.

    Conformally coated for optimal protection against harsh industrial environments, this board is designed to withstand the rigors of continuous operation without degradation.

    Equipped with Barrier-type terminal blocks, it provides superior isolation and safety during data transmission, ensuring smooth operation and reduced risk of electrical interference.

    Utilizing a functional revision of ‘C’ and artwork revision of ‘B’, this board is meticulously engineered to match the latest design standards, offering enhanced compatibility and performance enhancements over its predecessors.

    Each terminal block is precisely mounted on one long side of the board, facilitating easy connection to servo current sources through two dedicated input channels, thus optimizing the flow of critical control signals.
