Isolation Withstand Voltage: 5000VDC/1 minute
Auxiliary Power Supply: +12VDC, ±12VDC, +24VDC
Working Temperature: -20℃～+60℃
Temperature Drift: <300ppm/℃
Dimensions (Integrator): 86mm x 70mm x 73mm (L x W x H)
Functional Characteristics
No Input Saturation: Utilizes Rogowski principle, eliminating the need for magnetic cores commonly used in traditional transformer or Hall-effect principles, allowing for a wide input range without compromising performance.
Fast Response Time: Achieves response times in microseconds (us), suitable for applications requiring rapid signal detection, such as fault recording in power systems.
Wide Frequency Response: With a bandwidth range exceeding 20kHz, it can handle complex input waveforms, making it suitable for a variety of signal detection tasks.
Excellent Linearity: Outputs with a linearity of 0.2%, ensuring accurate representation of input signals.
High Accuracy: Overall accuracy within 1%, ensuring reliable measurements and control.
Compact and Lightweight: Compared to traditional transformer or Hall-effect-based products, the IS200EAUXH1A offers a smaller size and lighter weight, making it easier to integrate into various systems.
Application Scenarios
Electrical Systems: Suitable for measuring and controlling large AC currents in various electrical systems, including power distribution and transmission networks.
Electroplating and Electrolysis Industries: Utilized in processes requiring precise current measurements and control, ensuring efficient and safe operations.
Power System Monitoring: Can be used for fault recording, waveform analysis, and other monitoring tasks in power systems, enhancing their reliability and safety.
Industrial Automation: Integrated into industrial automation systems, providing real-time current measurements and control for various machines and processes.
