Input Signals:
Voltage, current, power (for analog-to-digital conversion)
Differential or single-ended (RS-422 or TTL/CMOS) for counting inputs
Output Signals: RS-232, RS-485
Operating Temperature: -10°C to +55°C
Protection Level: IP65
Dimensions: 110 mm x 110 mm x 54 mm
Functional Characteristics
High Accuracy and Speed: Utilizes high-precision measurement and conversion technology to ensure the accuracy and reliability of results.
Versatile Inputs: Supports multiple analog and digital input signals, including voltage, current, power, and differential or single-ended counting inputs.
Programmable Features: Each channel is independently programmable, with features such as programmable mode, polarity, and pre-scaler (1X, 2X, 4X).
Interrupt Functionality: Supports programmable interrupts for capturing or matching events, enabling real-time response to system changes.
Immediate Read Capability: Allows for immediate reading of counter values, providing real-time data access.
Direct Sensor Connection: Can directly connect to most sensors, simplifying system integration.
Application Scenarios
Power System: Used for measuring current, voltage, and power parameters in electrical systems.
Industrial Automation: Collects sensor data for control and analysis in automated manufacturing processes.
Test and Measurement: Employed in precision measurement applications requiring high accuracy and resolution.
General Purpose Conversion: Suitable for any situation where analog signals need to be converted into digital signals for further processing or analysis.
