Network Compatibility: Compatible with VMIC 5565 series reflective memory devices
Communication Protocols: Utilizes reflective memory technology for deterministic data sharing over fiber networks
Functional Characteristics
Independent Operation: The module operates independently of the CPU, not requiring any CPU processing to function.
Redundant Transmission: Supports redundant transmission mode operation, ensuring high availability and reliability.
Configurable Transmission Rates: Offers configurable transmission rates ranging from 43 MB/s (4-byte dynamic packet size) to 174 MB/s (64-byte dynamic packet size).
Extensive Node Support: Capable of communicating with up to 256 nodes on each network.
Diagnostic LEDs: Equipped with LED status indicators for OK, configuration, own data, and signal detection.
Application Scenarios
Industrial Automation: Used in industrial automation systems, specifically in PACSystem RX7i platforms, for deterministic data sharing between PLCs and compatible devices.
Process Control: Ideal for process control applications where real-time data sharing is crucial for seamless operation.
Redundant Systems: Essential in redundant systems, where the IC698RMX016 can serve as a link between two CPUs or as a node on a reflective memory network.
High-Speed Data Transmission: Suitable for applications requiring high-speed data transmission over fiber networks, such as real-time monitoring and control systems.
