Technical Specifications

• Number of Channels: 32
• I/O Type: Digital Input/Output (DIO)
• Input/Output Voltage: 24 VDC
• Current per Channel: 0.5 A
• Operating Temperature: -40°C to +70°C
• Protection Rating: IP20
• Dimensions: 7.87 inches (200 mm) x 3.94 inches (100 mm) x 1.57 inches (40 mm)
• Weight: 2.42 pounds (1.1 kg)

Functional Characteristics

• Digital Input/Output: The IC697CMM742 provides 32 channels of digital input and output capabilities, allowing it to interface with various sensors, actuators, and other digital devices.
• Flexibility: The module’s design offers flexibility in configuring and using the digital I/O channels, making it suitable for a wide range of industrial automation applications.
• Reliability: With its high-quality materials and manufacturing processes, the IC697CMM742 ensures reliable performance in harsh industrial environments.
• Easy Installation and Maintenance: The module is designed for simple installation and maintenance, minimizing downtime and enhancing system availability.
• Compatibility: Compatible with GE Fanuc 90-30 series PLCs, this module integrates seamlessly into existing systems and can be easily expanded or upgraded as needed.

Application Scenarios

The GE IC697CMM742 DIO module is suitable for a wide range of industrial automation applications requiring flexible and reliable I/O solutions, including but not limited to:

• Manufacturing: Used in manufacturing processes to interface with various sensors, switches, and actuators for monitoring and controlling production lines, machines, and equipment.
• Process Control: In process industries such as chemicals, pharmaceuticals, and food processing, the module is used to monitor and control process variables like temperature, pressure, flow rate, and level.
• Factory Automation: Integrated into factory automation systems for real-time monitoring and control of production processes, machines, and equipment.
• Machine Control: Used in machine control systems to interface with motors, drives, valves, and other actuators, enabling precise control of machine movements and operations.
• Remote Monitoring and Control: In remote monitoring and control applications, the IC697CMM742 DIO module allows for remote access and control of industrial equipment over networks.
