GE IC697CHS770
Application Scenarios
The GE IC697CHS770 digital input module is suitable for a wide range of industrial automation applications, including but not limited to:
- Machine Automation: Collects input signals from sensors and switches, enabling control of machines and processes.
- Process Control: Used in manufacturing lines, assembly lines, and other continuous or batch processes.
- Facility Management: Integrates with building automation systems for lighting, HVAC, and other facility-wide control.
- Automotive Industry: Applies in assembly lines, robotic cells, and other automotive manufacturing processes.
- Packaging and Sorting: Enables high-speed, accurate control of packaging machinery and sorting systems.
- Utilities: Assists in the control and monitoring of power plants, water treatment facilities, and other infrastructure.
Detailed content
Technical Specifications
- Model: IC697CHS770
- Type: Digital Input Module
- Input Voltage Range: Typically 12-48VDC (note: specifications may vary by model and manufacturer, refer to manufacturer’s documentation for exact range)
- Output Voltage: 5VDC (often used for internal signal processing or logic)
- Output Current: Maximum 10A (though the specific output current related to the module’s functionality might not be directly stated, this could be an indication of the overall module’s capacity or an associated specification)
- Efficiency: Greater than 90% (efficiency usually refers to power supply efficiency, but may be an indicator of the module’s overall energy consumption and efficiency in signal processing)
- Physical Dimensions: Approximately 170mm x 105mm x 32mm
- Weight: Approximately 120g (may vary depending on exact model and configuration)
- Operating Temperature: -20°C to +50°C
- Storage Temperature: -40°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Processor: 32-bit RISC processor (specifics may vary depending on manufacturer and model variant)
Functional Characteristics
- Digital Input: Accepts discrete or binary signals from sensors, switches, or other devices.
- Signal Processing: Converts incoming digital signals into a format suitable for processing by the PLC.
- Reliability: Designed for use in industrial environments, ensuring long-term operation and durability.
- Easy Integration: Easily integrates with other PLC modules and systems, providing flexibility in system design.
- Remote Control: Can be operated and monitored remotely, enhancing system management and efficiency
