GE IC697ALG230

The GE IC697ALG230 is a high-performance analog input base conversion module from the Series 90-30 line of products, originally manufactured by GE Fanuc (now Emerson Automation Solutions). This module is designed to convert analog signals (voltage or current) into digital signals for processing and control by PLCs.

WhatApp
WeChat

Detailed content

Technical Specifications

  • Model: IC697ALG230
  • Series: Series 90-30
  • Type: Analog Input Base Conversion Module
  • Channel Count: 8 channels
  • Input Types:
    • Configurable as voltage or current input
    • Voltage input range: ±10V
    • Current input range: 4-20mA
  • Resolution: 14-bit
  • Sampling Rate: Configurable
  • Input Configuration: Each channel can be independently configured for voltage or current input.
  • User-Defined Calibration: Allows for calibration of each channel based on actual requirements.

Functional Characteristics

  • Analog Signal Acquisition: Converts external analog signals (voltage, current, etc.) into digital signals for processing by PLCs.
  • Data Conversion: Transforms analog signals into digital signals that can be recognized and processed by PLCs.
  • Signal Conditioning: Provides signal suppression, amplification, and other processing to ensure accurate measurement.
  • Flexibility: The ability to configure each channel independently as voltage or current input adds flexibility to the module’s usage.
  • Accuracy: With a 14-bit resolution, the IC697ALG230 ensures high accuracy in analog-to-digital conversions.

Application Scenarios

The GE IC697ALG230 is widely used in various industrial automation applications, including but not limited to:

  • Process Control: In industries such as chemicals, petrochemicals, power generation, and water treatment, where it is used to measure and control temperature, pressure, flow rate, and other analog signals.
  • Machine Automation: For monitoring and controlling motor currents, fluid levels, and other analog parameters in automated machinery and equipment.
  • Data Acquisition Systems: As part of data acquisition systems that collect and process various analog signals for monitoring and analysis.
  • Industrial Automation Systems: Integrated into various industrial automation systems, including production lines, machine tools, and other equipment.
  • Building Automation: In building automation systems, such as HVAC control and lighting control, where it helps maintain optimal environmental conditions.
