Technical Specifications:

Number of Discrete Output Channels: 16
Output Voltage Range: 10-30 VDC (nominal 24 VDC)
Output Current per Channel: 0.5 A
Total Output Current: 4 A (across all channels)
Contact Resistance: Less than 1 Ω
Switching Time: Less than 2 ms
Common-Mode Rejection Ratio (CMRR): Greater than 60 dB
Noise Immunity: Greater than 10 V RMS
Operating Temperature Range: -40°C to 70°C
Storage Temperature Range: -40°C to 85°C
Power Consumption: 111 mA from the Bus Interface Unit (BIU) power supply
Dimensions: Approximately 90 mm x 30 mm x 25 mm (depending on exact model variant)
Weight: Approximately 100 grams
Protection: Built-in 5 A fuse for overcurrent protection
Output Response Time: 200 ms for 0.5 A resistive load
Output Voltage Drop: Maximum 0.5 V
Connection Type: Terminal block connection, supporting AWG #14 to AWG #22 wires
Functional Characteristics:

High Current Output Capability: Each channel can provide up to 0.5 A of output current, making it suitable for controlling devices with moderate to high power requirements.
Versatile Compatibility: Designed to be installed on a Bus Interface Unit (BIU), allowing seamless integration into GE Fanuc’s Field Control Series PLC systems.
Visual Indication: Equipped with individual status LED indicators for each output channel, providing instant feedback on the on/off status of each output.
Protection Features: Includes a built-in 5 A fuse for each module, protecting against overcurrent conditions and helping to prevent damage to connected devices.
Easy Maintenance: Modular design allows for easy replacement of individual modules in case of failure, minimizing downtime.
Application Scenarios:

Relay Control: Ideal for controlling relays in various industrial automation systems.
Motor Control: Can be used to control motors and actuators requiring discrete outputs.
Solenoid Control: Suitable for controlling solenoids and valves in process control applications.
Indicator Control: Commonly used to control indicator lights, such as warning or status lights.
General Industrial Automation: Widely applicable in various industries, including manufacturing, processing, and control systems, where high reliability and flexibility are required.
