Isolation Withstand Voltage: 5000 VDC/1 minute
Auxiliary Power Supply: +12 VDC, ±12 VDC, +24 VDC
Operating Temperature: -20°C to +60°C (or -22°F to +150°F depending on sources)
Temperature Drift: <300 ppm/°C
Channel Update Rate: 1 second, typical
Energy Consumption: 4.6 watts max. (another source mentions 10.5 watts)
Weight: 0.82 kg (approx.)
Dimensions: 86x70x73mm (integral part)
Communication: USB-B interface, RS422 interface
Cable Length: USB data cable length: 5 meters
Functional Characteristics:
No Input Saturation: Utilizes Rogowski principle, eliminating the need for magnetic cores used in traditional transformer or Hall principles, allowing for a wide input range without compromising performance.
Fast Response Time: Capable of reaching microsecond (us) level response time, suitable for fault recording in power systems.
Wide Bandwidth: Frequency response range exceeding 20 kHz, suitable for signal detection with complex input waveforms.
Good Linearity: Output linearity up to 0.2%, accurately reflecting input signal size.
High Accuracy: Overall accuracy within 1%.
Compact and Lightweight: Compared to traditional transformer or Hall principle products, it has a smaller volume and lighter weight under the same input range conditions.
Application Scenarios:
Electrical Systems: Suitable for the measurement and control of large AC currents in various electrical systems.
Electroplating and Electrolysis Industries: Can be applied in these industries for precise current control and monitoring.
Industrial Automation: As part of a DCS (Distributed Control System) or PLC (Programmable Logic Controller) system, providing digital output control for various industrial processes.
Additional Information:
Installation: The module is designed for DIN35 rail mounting or screw fixation.
Wiring: The product consists of a sensor head and an integrator, connected via shielded wire. Detailed wiring instructions are provided in the installation manual.
Indicators: Equipped with LED indicators for status monitoring and fault detection.
Availability: Pricing and availability may vary depending on suppliers and purchasing quantities. It is recommended to inquire directly with suppliers for the most up-to-date information.
