Product Type:Gate Driver Power Module

Model Number:DS200GDPAG1AEB

Power Rating:Up to 1500W

Operating Voltage Range:DC 10V to 50V

Operating Current Range:Up to 30A

Input Power Factor Correction:Class A

Efficiency:≥ 90%

Environmental Temperature Range:-20°C to +70°C

Humidity Range:5% to 95% non-condensing

    The GE DS200GDPAG1AEB is engineered with precision and reliability, making it an indispensable component for advanced industrial control systems. Its opto-isolated design ensures isolation between the input and output circuits, preventing any potential electrical interference and enhancing system safety.

    Featuring a robust operating voltage range of 12VDC and capable of delivering up to 5A of current, this module is optimized for high-efficiency power delivery, supporting a wide array of industrial applications from motor control to complex automation processes.

    Equipped with a maximum gate voltage rating of 40V, the DS200GDPAG1AEB is versatile enough to handle a broad spectrum of load requirements, ensuring compatibility and performance across different industrial equipment.

    The module boasts an impressive insulation resistance of ≥10MΩ, ensuring reliable operation even in harsh environments. With its ability to operate within an ambient temperature range of -40°C to +85°C, it is suitable for use in extreme conditions, providing consistent performance throughout its operational life.

    Compact yet powerful, the DS200GDPAG1AEB measures just 50mm x 30mm x 15mm, allowing for easy integration into existing control systems without compromising on space. Its lightweight design (20g) facilitates quick installation and maintenance, minimizing downtime and enhancing operational efficiency.
