Baud Rate:300 to 19200 baud

Frequency Range:25 to 60 Hz nominal

Humidity Tolerance:Up to 90% non-condensing

Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01

Relay Dimensions:Approximately 18cm W, 16.5cm L, 21.5cm H

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states, and 8 output relays

    The GE 750-P5-G1-S1-HI-A20-R is a top-tier feeder management relay, engineered to enhance efficiency and reliability in power distribution systems. This device is equipped with 5 A phase current inputs and 1 A zero sequence current inputs, along with sensitive ground current inputs, ensuring comprehensive monitoring and control.

    With its active communications protocol support for Modbus RTU or DNP 3.0, the relay facilitates seamless integration with existing systems, providing flexible communication options for real-time data exchange. Its robust design allows for operation in harsh environments, making it ideal for industrial applications where reliability and performance are paramount.

    This unit can be easily mounted on a standard 19-inch panel, either individually or alongside other 750 series units, optimizing space utilization in control rooms and switchgear cabinets. The built-in breaker closed LED indicator provides immediate visual feedback on system status, enhancing operational safety and maintenance efficiency.

    Featuring a pollution degree rating of II, the 750-P5-G1-S1-HI-A20-R is constructed from high-quality materials to withstand harsh conditions, ensuring long-term durability and minimal maintenance requirements. Its waveform capture channels provide comprehensive monitoring of currents, voltages, and logic input states, facilitating precise control and protection.
