GE 531X304IBDASG1 Base Drive Card for AC2000 System, Digital Signal Processor Compatible
The GE 531X304IBDASG1 is a Base Drive Card designed for the AC2000 system. It is compatible with various GE F31X systems and features essential electronic components for efficient signal processing and power distribution in industrial automation applications.
Detailed content
Manufacturer:General Electric
Model Number:531X304IBDASG1
Compatibility:GE AC2000 System
Dimensions:Customized based on the actual size
Weight:Customized based on the actual weight
Operating Voltage:Varies based on application
Current Rating:Varies based on application
Component Count:Over 30 key components including transformers, connectors, and heat sinks
The GE 531X304IBDASG1 Base Drive Card is meticulously crafted for seamless integration within the GE AC2000 system. Designed with robust engineering principles, this card ensures reliable performance under demanding industrial conditions. Key design features include multiple transformer configurations and a vertical pin header connector, facilitating easy installation and maintenance. Two parallel heat sinks provide excellent thermal management, enhancing the longevity and efficiency of the system. The inclusion of jumper switches allows for customizable settings, providing flexibility for diverse applications. Complemented by an array of transistors, resistors, and diodes, the card ensures stable and precise signal processing. With its advanced design and comprehensive component integration, the GE 531X304IBDASG1 is indispensable for modern industrial automation systems requiring high precision and reliability.
