Input Power:
110-250V DC
100-240V AC
Phase Current Input: 1 A and 5 A
Display Version: Enhanced
Maximum Environmental Humidity: Up to 95% non-condensing
Number of Digital/Switch Inputs: 6, optically isolated
Functional Characteristics (Features of GE 369-HI-R-M-0-0-0-E)
Electromagnetic Relay: Controls the circuit by means of an electromagnet that engages and releases contacts.
High Durability: Long mechanical and electrical lifespans, suitable for long-term stable operation in industrial automation equipment.
Protection and Control: Provides protection and control for motors and their associated components through features like pre-trip alarms and over-torque correction.
Measurement Capabilities: Monitors voltage, watts, frequency, and energy, generating protection functions based on generated data.
Event Logging: Reports trip causes and associated data immediately after a trip, aiding in problem analysis.
Pre-Trip Alarm: Notifies users before a trip occurs due to reasons such as ground faults, mechanical blockages, or RTD over-temperature.
Enhanced Diagnostics and Panel: The ‘e’ in the model number indicates enhanced diagnostic functions and an enhanced panel.
Applications (Application Scenarios of GE 369-HI-R-M-0-0-0-E)
Power Plants: Used to monitor and protect generators, transformers, switchgear, and other electrical equipment from faults and overloads.
Substations: Found in substations to monitor and safeguard high-voltage equipment and distribution devices like transformers and cables.
Transmission and Distribution Systems: Ensures safe distribution of electrical energy to end-users by detecting current overloads, voltage abnormalities, and other power system issues.
Industrial Facilities: Protects critical production equipment from damage or downtime, maintaining industrial process stability and continuity.
Aerospace: Similar protection devices may be utilized in the aerospace industry for monitoring and safeguarding spacecraft and related equipment (though specifically for GE 369-HI-R-M-0-0-0-E, aerospace application is not directly mentioned).
