Technical Specifications

1. Type:
   • Category: Managed Network Switch
2. Ports:
   • Ethernet Ports: 24 x 10/100/1000Base-T (Gigabit Ethernet) ports.
   • Fiber Ports: 4 x 1G/10G SFP/SFP+ (Small Form-factor Pluggable) uplink ports.
3. Performance:
   • Switching Capacity: Up to 128 Gbps.
   • Forwarding Rate: Up to 95.2 Mpps (Million Packets Per Second).
4. Features:
   • Layer 2/3 Switching: Supports both Layer 2 (Data Link) and Layer 3 (Network) switching functionalities.
   • Quality of Service (QoS): Implements QoS policies to prioritize network traffic and manage bandwidth.
   • Security: Includes security features such as 802.1X authentication, ACLs (Access Control Lists), and encryption protocols.
5. Management:
   • Interfaces: Web-based GUI, CLI (Command Line Interface), and SNMP (Simple Network Management Protocol) for network management.
   • Configuration: Supports configuration through Foxboro’s management tools and other standard network management systems.
6. Redundancy and Reliability:
   • Power Supply: Typically supports redundant power supplies for high availability.
   • Failover: Designed to ensure network reliability with failover mechanisms and redundancy options.
7. Environmental Conditions:
   • Operating Temperature: Generally from 0°C to 45°C (32°F to 113°F).
   • Humidity: Operates in environments with up to 90% relative humidity (non-condensing).
8. Dimensions and Weight:
   • Form Factor: 1U rack-mounted.
   • Size: Approximately 1.72 x 17.5 x 10.6 inches (H x W x D).
   • Weight: About 10 lbs (4.5 kg).

Functional Features

1. High Performance:
   • Throughput: Designed to deliver high throughput and low latency, suitable for demanding network environments.
   • Scalability: Capable of handling high traffic loads and scaling as network needs grow.
2. Advanced Networking Capabilities:
   • VLAN Support: Provides VLAN (Virtual Local Area Network) support to segment network traffic.
   • Routing: Supports static and dynamic routing protocols to manage network traffic efficiently.
3. Enhanced Security:
   • Access Control: Implements advanced access control and network segmentation to safeguard sensitive data.
   • Monitoring and Alerts: Includes network monitoring and alerting features to detect and respond to issues promptly.
4. Flexible Connectivity:
   • Mixed Media: Offers both copper and fiber connectivity to accommodate different network designs and requirements.
   • Uplink Options: Features flexible uplink options with 1G and 10G speeds for high-bandwidth connections.

Application Scenarios

1. Industrial Networks:
   • Usage: Ideal for industrial environments where reliability and performance are critical.
   • Benefits: Supports automation and control systems, enhancing operational efficiency.
2. Enterprise Networks:
   • Application: Suitable for medium to large enterprises requiring robust network performance and management.
   • Impact: Ensures high availability and reliable connectivity for business-critical applications.
3. Data Centers:
   • Function: Utilized in data centers for high-speed interconnects and large-scale network deployments.
   • Advantages: Supports data-intensive applications and high-traffic volumes.
4. Campus Networks:
   • Role: Used in campus environments for high-density network connectivity and advanced management features.
   • Effect: Provides reliable network access and supports a variety of campus applications.

Additional Considerations

• Installation: Follow Foxboro’s installation and configuration guidelines for optimal performance and integration.
• Technical Support: For further details, troubleshooting, or configuration assistance, consult Foxboro’s technical documentation or support services.
