Technical Specifications

1. Type:
   • Category: Managed Switch
2. Ports:
   • Ethernet Ports: 24 x 10/100/1000Base-T (Gigabit Ethernet) ports.
   • Fiber Ports: 4 x 1G/10G SFP/SFP+ (Small Form-factor Pluggable) uplink ports.
3. Performance:
   • Switching Capacity: Up to 128 Gbps, depending on configuration and usage.
   • Forwarding Rate: Up to 95.2 Mpps (Million Packets Per Second).
4. Features:
   • Layer 2/3 Switching: Supports Layer 2 and Layer 3 switching, including VLANs, static routing, and dynamic routing protocols.
   • Quality of Service (QoS): Implements QoS policies to prioritize network traffic and ensure performance for critical applications.
   • Security: Provides robust security features such as 802.1X authentication, Access Control Lists (ACLs), and Secure Socket Layer (SSL) encryption.
5. Management:
   • Management Interfaces: Web-based GUI, CLI (Command Line Interface), and SNMP (Simple Network Management Protocol) for network management and monitoring.
   • Configuration: Supports configuration via Extreme Networks’ management software, as well as standard network management tools.
6. Redundancy and Reliability:
   • Power Supply: Supports redundant power supplies to ensure continuous operation.
   • Failover: Includes mechanisms for failover and redundancy to maintain network availability.
7. Environmental Conditions:
   • Operating Temperature: Typically from 0°C to 45°C (32°F to 113°F).
   • Humidity: Designed to operate in environments with up to 90% relative humidity (non-condensing).
8. Dimensions and Weight:
   • Form Factor: 1U rack-mountable chassis.
   • Size: 1.72 x 17.5 x 10.6 inches (H x W x D).
   • Weight: Approximately 10 lbs (4.5 kg).

Functional Features

1. High Performance:
   • Throughput: Delivers high throughput with low latency, suitable for demanding network environments.
   • Scalability: Can handle large amounts of traffic and scale to accommodate growing network needs.
2. Advanced Networking:
   • VLAN Support: Allows for virtual LAN configurations to segment network traffic and improve security.
   • Routing Protocols: Supports dynamic routing protocols like OSPF and BGP for efficient network routing.
3. Enhanced Security:
   • Access Control: Provides advanced access control and network segmentation to protect sensitive data.
   • Network Monitoring: Includes network monitoring tools and diagnostic features to troubleshoot and maintain network health.
4. Flexible Connectivity:
   • Fiber and Copper: Offers both fiber and copper connectivity options to suit different network architectures and requirements.
   • Uplink Ports: Flexible uplink options with support for both 1G and 10G speeds for high-bandwidth connections.

Application Scenarios

1. Enterprise Networks:
   • Usage: Ideal for medium to large enterprises requiring high-performance networking with robust management and security features.
   • Benefits: Ensures reliable and secure network connectivity, supporting a wide range of applications and services.
2. Data Centers:
   • Application: Used in data centers for high-speed interconnects and high-density network deployments.
   • Impact: Enhances data center efficiency and supports large-scale data processing and storage.
3. Campus Networks:
   • Function: Suitable for campus environments where high throughput and flexible connectivity are essential.
   • Advantages: Supports a wide range of devices and applications, ensuring seamless network operation across campus facilities.
4. Industrial and Manufacturing:
   • Role: Provides network connectivity in industrial and manufacturing environments, where reliability and performance are crucial.
   • Effect: Enhances operational efficiency and supports industrial automation and control systems.

Additional Considerations

• Installation: Ensure proper installation and configuration following Extreme Networks’ guidelines for optimal performance.
• Technical Support: For detailed specifications, configuration assistance, or troubleshooting, consult Extreme Networks’ official documentation or contact their technical support team.
