Technical Specifications

• Model: KJ4001X1-BE1
• System: Emerson DeltaV DCS
• Type: Communication Interface Module
• Power Supply: Powered through the DeltaV system’s backplane, typically 24V DC.
• Interfaces: Includes multiple communication ports for connecting field devices and other system components.
• Size: Standard 2U module size, designed to fit into a standard DeltaV system rack.

Functional Features

• Data Communication: Provides reliable communication interfaces for transmitting data from field devices to the DeltaV control system.
• High Reliability: Designed for industrial environments, offering durability and stability for long-term system operation.
• Easy Integration: Seamlessly integrates with the DeltaV system, supporting plug-and-play installation to simplify system configuration and maintenance.
• Diagnostic Capabilities: Features self-diagnostic functions to monitor the module’s operational status and provide alerts or alarms in case of issues.

Application Scenarios

• Process Control: Primarily used in process automation control systems in industries such as oil and gas, chemical, and pharmaceuticals.
• Data Acquisition: Utilized in industrial automation systems for collecting and transmitting data from field devices.
• System Integration: Acts as a key component in integrating various field devices and subsystems into a unified control platform within the DeltaV system.

Key Considerations

• Compatibility: The KJ4001X1-BE1 is specifically designed for the DeltaV system, ensuring seamless compatibility with other modules and software within the system.
• Maintenance: Regular checks and maintenance are required to ensure the module’s continued stable operation.
• Upgradability: The module supports system upgrades and expansions, capable of meeting evolving industrial control needs.
