EMERSON KJ3004X1-BA1: Fieldbus H1 Module, Precision Control for Industrial Automation
The EMERSON KJ3004X1-BA1 Fieldbus H1 Module is an essential component for industrial automation systems, designed to facilitate seamless communication and data transfer in manufacturing environments.
Detailed content
Product Type:Fieldbus H1 Module
Product ID:KJ3004X1-BA1
Manufacturer:EMERSON
Series:DeltaV
LocalBus Power Rating:12 VDC at 150 mA
Bussed Field Power Rating:24 VDC at 3.2 A
Terminal Block Key Position:B4
Weight:0.2 kg
Max Current:3.2 A
Voltage Rating:32 VDC
Port Count:1
Communication Protocol:Fieldbus H1
Application Environment:Indoor industrial settings
The Emerson KJ3004X1-BA1 Fieldbus H1 Module is engineered for high-performance operation in demanding industrial environments, offering unparalleled reliability and durability.
This module features an efficient LocalBus power supply capable of handling 12 volts DC at 150 milliamps, ensuring stable communication within the control system.
With a bussed field power rating of 24 volts DC at 3.2 amperes, the module provides robust power to connected devices, enhancing overall system capabilities.
Positioned for optimal signal integrity, the card’s terminal block is located at key position B4, facilitating easy connection and disconnection for maintenance and troubleshooting.
Weighing in at just 0.2 kilograms, this module is lightweight yet sturdy, making it suitable for installation in compact spaces without compromising on functionality or performance.
