Technical Specifications

• Type: Human-Machine Interface (HMI) Panel
• Display:
  • Screen Size: 10.4 inches
  • Resolution: 800 x 600 pixels (SVGA)
  • Touchscreen: Resistive touchscreen for direct user interaction
  • Display Type: TFT color display, ensuring clear and vivid visuals suitable for industrial environments
• Processor: Equipped with a robust processor designed to handle various HMI applications efficiently, supporting smooth operation even under demanding conditions.
• Memory:
  • RAM: Typically features sufficient RAM to support HMI tasks (exact amount would be specified in the datasheet).
  • Flash Memory: Includes flash memory for storing system software, applications, and user data.
• Operating System: Generally runs on an embedded operating system like Windows CE, which supports various industrial HMI software applications.
• Connectivity:
  • Serial Ports: Includes RS232/RS485 serial communication ports for connecting to other control devices and PLCs.
  • Ethernet: Features an Ethernet port for network communication, allowing integration into larger control networks.
  • USB Ports: Provides USB ports for connecting peripherals such as USB drives, keyboards, or mice.
  • MPI Interface: The model number suggests the presence of an MPI (Multi-Point Interface) port, which is often used in Siemens PLC communication.
• Power Supply: Operates on a standard 24V DC power supply, typical for industrial control devices.
• Mounting: Designed for panel mounting, making it easy to install in control panels or cabinets.

Features

• Graphical User Interface: Offers an intuitive and customizable graphical interface that allows operators to monitor and control industrial processes effectively.
• Data Logging: Capable of logging data from various sensors and connected devices, with options to view logs on the screen or export them for further analysis.
• Alarm Management: Features built-in alarm capabilities that notify operators of any issues, which can be configured to display, log, or trigger external alerts.
• Programmability: Supports custom application development through Eaton’s programming software, allowing for tailored solutions to meet specific operational needs.
• Remote Access: May support remote access features, enabling monitoring and control of systems from off-site locations.
• Rugged Construction: Built to withstand industrial conditions such as dust, vibration, and temperature variations, ensuring reliable operation in challenging environments.

Application Scenarios

• Industrial Automation: Commonly used in manufacturing plants, the XVS-440-10MPI-1-1AD serves as an operator interface for monitoring and controlling machinery and production lines.
• Process Control: Applied in various process industries, including chemical, oil and gas, and pharmaceuticals, where precise control and monitoring of processes are critical.
• Building Automation: Can be used in building management systems to control and monitor HVAC systems, lighting, and other building infrastructure.
• Energy Management: Suitable for energy management applications, providing a platform to monitor and control energy usage and optimize efficiency.
