Technical Specifications

1. Model: 33075
2. Type: Proximity Probe Extension Cable
3. Function: Extends the reach of proximity probes, facilitating the connection between the probes and the monitoring system over longer distances.
4. Cable Specifications:
   • Length: Typically available in various lengths, with common options including 25 feet (7.6 meters), 50 feet (15.2 meters), or custom lengths. Verify the exact length for your application.
   • Conductor Type: Utilizes shielded twisted pair conductors to maintain signal integrity and reduce electromagnetic interference (EMI).
   • Shielding: Features robust shielding to protect against external electrical noise and interference, ensuring accurate signal transmission.
5. Electrical Characteristics:
   • Impedance: Designed to match the impedance of the connected proximity probes, maintaining consistent signal quality.
   • Voltage Rating: Built to handle the voltage levels used in proximity probe systems. Specific voltage ratings are detailed in the product datasheet.
6. Environmental Conditions:
   • Temperature Range: Suitable for operation within a wide industrial temperature range, typically from -40°C to +85°C (-40°F to +185°F).
   • Relative Humidity: Designed to perform in environments with relative humidity up to 95% (non-condensing).

Features

1. Reliable Signal Transmission: Ensures consistent and accurate signal transmission from the proximity probes to the monitoring system, crucial for accurate machinery diagnostics.
2. Durable Construction: Built to withstand harsh industrial conditions, including temperature extremes and mechanical stress.
3. Effective Shielding: Provides shielding to reduce electromagnetic interference (EMI), maintaining signal integrity and accuracy.
4. Flexible Installation: Allows for flexible placement of proximity probes by extending their reach, accommodating various installation needs.
5. Compatibility: Designed to integrate seamlessly with Bently Nevada’s 3300 Series proximity probes and monitoring systems.

Application Scenarios

1. Machinery Protection: Used to connect proximity probes to monitoring systems in critical machinery protection applications, such as in turbines, compressors, and generators.
2. Condition Monitoring: Facilitates the extension of proximity probes for continuous monitoring of machinery health, enabling the detection of potential issues before they lead to failures.
3. Industrial Automation: Applied in industrial automation systems where extended probe placement is required for accurate measurements and reliable operation.
4. Process Control: Useful in process control environments for extending probe connections and ensuring stable operation of machinery.

Installation and Configuration

1. Mounting:
   • Form Factor: Typically routed and secured in industrial environments to connect proximity probes with the monitoring system. Proper installation is necessary to ensure reliable signal transmission.
   • Installation: Involves connecting the cable to the proximity probes and monitoring system, following the provided installation instructions.
2. Wiring:
   • Connections: Connects to proximity probes and monitoring systems using standard industrial wiring practices. Detailed wiring diagrams and instructions are provided in the product documentation.
3. Configuration:
   • Compatibility: Ensure that the extension cable is compatible with your specific Bently Nevada system components. Review the product documentation for detailed compatibility information.
   • Integration: Integrates with the 3300 Series monitoring system for optimal performance and data acquisition. Configuration instructions are included in the product manual.
