Technical Specifications

1. Model: 330180-50-00
2. Type: Proximity Probe Extension Cable
3. Function: Extends the connection between proximity probes and the monitoring system, facilitating the placement of probes at desired locations for accurate measurements.
4. Cable Specifications:
   • Length: The part number suggests a length of 50 feet (or 15.24 meters). Specific lengths can be confirmed with the product datasheet.
   • Conductor Type: Includes shielded twisted pair conductors to minimize electrical noise and ensure accurate signal transmission.
   • Shielding: Features effective shielding to protect against electromagnetic interference (EMI) and maintain signal quality.
5. Electrical Characteristics:
   • Voltage Rating: Designed to handle the voltage levels typically used in proximity probe systems. Specific ratings are detailed in the datasheet.
   • Impedance: Matches the impedance of the connected proximity probes to ensure accurate signal transmission.
6. Environmental Conditions:
   • Temperature Range: Operates within an industrial temperature range, typically from -40°C to +85°C (-40°F to +185°F).
   • Relative Humidity: Suitable for environments with relative humidity up to 95% (non-condensing).

Features

1. Reliable Signal Transmission: Ensures high-quality signal transfer from proximity probes to monitoring systems, crucial for accurate measurement and monitoring.
2. Durable Construction: Built to withstand harsh industrial environments, including high temperatures and mechanical stress.
3. Effective Shielding: Includes shielding to reduce electromagnetic interference, ensuring stable and accurate signal transmission.
4. Flexible Installation: Allows for flexible placement of proximity probes by extending the reach of the probes, adapting to various installation requirements.
5. Compatibility: Specifically designed for use with Bently Nevada’s 3300 Series proximity probes and monitoring systems.

Application Scenarios

1. Machinery Protection: Used to connect proximity probes to monitoring systems in machinery protection applications, enabling precise monitoring of rotating machinery such as turbines, generators, and motors.
2. Condition Monitoring: Facilitates the connection of proximity probes to data acquisition systems, enabling continuous monitoring and assessment of machinery health.
3. Industrial Automation: Applied in industrial automation systems where precise signal transmission is essential for maintaining system reliability and performance.
4. Process Control: Useful in process control environments to ensure accurate and reliable connections between sensors and monitoring equipment, maintaining stable operation of machinery.

Installation and Configuration

1. Mounting:
   • Form Factor: Typically routed and mounted in industrial environments to connect proximity probes with monitoring systems. Proper installation is essential for maintaining signal integrity and durability.
2. Wiring:
   • Connections: Connects to proximity probes and monitoring systems using standard industrial wiring practices. Detailed wiring diagrams and installation instructions are provided in the product manual.
3. Configuration:
   • Compatibility: Ensure that the extension cable is compatible with the specific proximity probes and monitoring systems in use. Configuration involves proper connection and routing to maintain system functionality.
