Technical Specifications

1. Model: 330130-045-01-CN
2. Type: Vibration Probe System
3. Function: Measures vibration and displacement in rotating machinery through proximity probes.
4. Measurement Specifications:
   • Probe Type: Typically an eddy current proximity probe used for precise measurement of vibration and displacement.
   • Measurement Range: Usually up to ±2 inches (±50 mm), though the exact range may vary based on the specific probe configuration and application.
   • Frequency Response: Designed to handle high-frequency vibrations, typically up to several kHz, depending on the application.
5. Electrical Characteristics:
   • Power Supply: Operates on 24V DC, which is standard for many industrial monitoring systems.
   • Output: Provides analog output signals compatible with condition monitoring systems for real-time data acquisition.
6. Environmental Conditions:
   • Temperature Range: Suitable for operation within a temperature range of -40°C to +70°C (-40°F to +158°F).
   • Relative Humidity: Designed for environments with relative humidity up to 95% (non-condensing).

Features

1. High Accuracy: Provides precise measurements of vibrations and displacements, essential for effective condition monitoring and protection.
2. Real-Time Monitoring: Delivers continuous feedback on machinery condition, allowing for early detection of potential issues and prompt corrective actions.
3. Durable Construction: Built to withstand harsh industrial environments, ensuring reliable performance in challenging conditions.
4. Integration Capability: Compatible with Bently Nevada’s 3300 Series modules and other monitoring systems, facilitating a comprehensive machinery health monitoring solution.
5. Versatility: Applicable to a wide range of industrial machinery, including turbines, compressors, pumps, and motors.

Application Scenarios

1. Machinery Protection: Used to monitor critical machinery for vibration and displacement to prevent damage and ensure safe operation.
2. Condition Monitoring: Essential for ongoing health assessment of machinery, supporting predictive maintenance and early fault detection.
3. Industrial Automation: Employed in automation systems where accurate monitoring of machinery conditions is crucial for maintaining performance and efficiency.
4. Process Control: Useful in process control environments to monitor and maintain the stability and efficiency of rotating machinery.

Installation and Configuration

1. Mounting:
   • Form Factor: Typically mounted on a bracket or fixture close to the rotating shaft. Proper alignment and secure mounting are necessary for accurate measurement.
   • Installation: Involves precise positioning of the probe relative to the shaft and connection to the monitoring system. Detailed installation procedures are provided in the product manual.
2. Wiring:
   • Connections: Requires appropriate wiring to connect the probe to the monitoring system, including connections for power supply and signal output. Wiring diagrams and instructions are included in the product documentation.
3. Configuration:
   • Calibration: Calibration is necessary to ensure accurate displacement measurements. Specific calibration procedures are outlined in the product manual.
   • Integration: Designed to work with Bently Nevada 3300 Series modules and other monitoring systems. Configuration details are provided in the product documentation.
