Technical Specifications

1. Model: 330130-045-00-00
2. Type: Vibration Probe System
3. Function: Measures vibration levels and shaft displacement using proximity probes.
4. Measurement Specifications:
   • Probe Type: Eddy current proximity probe designed for precise measurement of vibrations and displacement.
   • Measurement Range: Typically measures displacement within a range of ±2 inches (±50 mm), although the exact range may depend on specific configuration and application requirements.
   • Frequency Response: Capable of handling high-frequency vibrations, generally suitable for frequencies extending up to several kHz.
5. Electrical Characteristics:
   • Power Supply: Operates on a 24V DC power supply, which is common in industrial monitoring systems.
   • Output: Provides analog output signals that can be interfaced with monitoring systems for real-time data analysis and acquisition.
6. Environmental Conditions:
   • Temperature Range: Designed to operate in a temperature range of -40°C to +70°C (-40°F to +158°F).
   • Relative Humidity: Suitable for environments with relative humidity up to 95% (non-condensing).

Features

1. High Precision: Offers accurate measurements of vibration and displacement, crucial for effective monitoring and protection of machinery.
2. Real-Time Feedback: Provides continuous, real-time data on machinery conditions, allowing for early detection of issues and timely corrective actions.
3. Robust Construction: Built to endure harsh industrial environments, ensuring reliability and durability under challenging conditions.
4. Integration Capabilities: Seamlessly integrates with Bently Nevada’s 3300 Series modules and other condition monitoring systems, enabling a comprehensive monitoring solution.
5. Versatility: Applicable across a broad range of industrial machinery, including turbines, compressors, pumps, and motors.

Application Scenarios

1. Machinery Protection: Utilized to monitor critical machinery for vibration and displacement to prevent damage and maintain safe operational conditions.
2. Condition Monitoring: Provides essential data for ongoing health assessment of machinery, supporting predictive maintenance and early fault detection.
3. Industrial Automation: Employed in automation systems where precise measurement of machinery conditions is essential for maintaining performance and efficiency.
4. Process Control: Useful in process control environments to monitor and ensure the stability and efficiency of rotating machinery.

Installation and Configuration

1. Mounting:
   • Form Factor: The probe is generally mounted on a bracket or fixture close to the rotating shaft. Accurate alignment and secure mounting are critical for reliable measurements.
   • Installation: Involves correct positioning of the probe relative to the shaft and connection to the monitoring system. Installation details are provided in the product manual.
2. Wiring:
   • Connections: Requires appropriate wiring to connect the probe to the monitoring system, including connections for power supply and signal output. Wiring diagrams and installation instructions are available in the product documentation.
3. Configuration:
   • Calibration: Calibration is necessary to ensure accurate displacement measurements. Specific calibration procedures are outlined in the product manual.
   • Integration: Designed to work with Bently Nevada 3300 Series modules and other monitoring systems. Configuration details are provided in the product documentation.
