1. Model: 330104-00-06-10-02-00
2. Type: Vibration Probe System
3. Function: Measures vibration levels and shaft displacement in rotating machinery components using proximity probes.
4. Measurement Specifications:
   • Probe Type: Eddy current proximity probe.
   • Measurement Range: Typically designed to handle displacement measurements within a range of up to ±2 inches (±50 mm), though exact measurement ranges depend on the specific configuration.
   • Frequency Response: Capable of capturing high-frequency vibrations, generally suitable for a frequency range up to several kHz.
5. Electrical Characteristics:
   • Power Supply: Operates on a 24V DC power supply, common for industrial monitoring systems.
   • Output: Provides analog output signals that can be connected to monitoring systems for real-time data analysis and condition monitoring.
6. Environmental Conditions:
   • Temperature Range: Designed for operation in a temperature range from -40°C to +70°C (-40°F to +158°F).
   • Relative Humidity: Suitable for environments with relative humidity up to 95% (non-condensing).

Features

1. High Accuracy: Provides precise measurements of displacement and vibration, crucial for accurate monitoring and protection of machinery.
2. Real-Time Monitoring: Offers real-time feedback, enabling prompt detection of potential issues and facilitating timely intervention.
3. Robust Construction: Built to withstand harsh industrial environments, ensuring reliable operation in challenging conditions.
4. Integration Capability: Designed to integrate seamlessly with Bently Nevada’s 3300 Series modules and other monitoring systems, providing a comprehensive solution for machinery condition monitoring.
5. Versatile Application: Suitable for a wide range of industrial machinery applications including turbines, compressors, pumps, and motors.

Application Scenarios

1. Machinery Protection: Used in critical machinery protection systems to monitor vibrations and displacement, helping to prevent damage and ensure safe operation.
2. Condition Monitoring: Essential for continuous monitoring of machinery health, providing valuable data for predictive maintenance and early fault detection.
3. Industrial Automation: Applied in industrial automation systems where accurate measurement of machinery conditions is crucial for maintaining performance and reliability.
4. Process Control: Useful in process control environments where monitoring the condition of rotating machinery is necessary for process stability and efficiency.

Installation and Configuration

1. Mounting:
   • Form Factor: The probe is typically mounted on a bracket or similar fixture near the rotating shaft. Proper alignment and secure mounting are critical for accurate measurements.
   • Installation: Involves precise positioning of the probe and connecting it to the monitoring system. Detailed installation instructions are provided in the product manual.
2. Wiring:
   • Connections: Requires wiring to connect the probe to the monitoring system, including power supply and signal output connections. Wiring diagrams and installation instructions are included in the product documentation.
3. Configuration:
   • Calibration: Calibration procedures are necessary to ensure accurate displacement measurements. Refer to the product manual for specific calibration instructions.
   • Integration: Integrates with Bently Nevada 3300 Series modules and other monitoring systems for a comprehensive monitoring solution. Configuration details are provided in the product documentation.
