Product Type:Digital Output Module

Model:DO232

Number of Outputs:32

Output Current:1 A

Total Current:Max. 8 A

Weight:0.65 kg

Dimensions (WxDxH):170 x 100 x 30 mm

Operating Voltage Range:12 V to 30 V DC

Operating Temperature Range:-25°C to +70°C

Input Voltage:24 VDC

Current Consumption:80 mA at 5 V

Isolation:Electrical isolation

Compliance:CE certified

    The BACHMANN DO232 Digital Output Module is engineered with advanced semiconductor technology, ensuring exceptional switching performance and low power consumption, making it an ideal choice for demanding industrial applications.

    Each of the 32 digital output channels is capable of driving loads up to 2 A, providing the flexibility to control a wide range of devices. The module supports high current output, which is essential for powering heavy-duty actuators and motors.

    With its compact design and DIN rail mounting capability, the DO232 seamlessly integrates into existing control panels, saving space and simplifying installation. Its robust IP20 protection rating ensures durability against dust and minor impacts.

    The module features fast response times and reliable operation within a broad temperature range (-20°C to +70°C), enabling it to function effectively in various industrial environments. It is equipped with comprehensive protection mechanisms to safeguard against overvoltage, overcurrent, and short-circuit conditions.

    Backed by BACHMANN’s commitment to quality and customer service, the DO232 Digital Output Module comes with a comprehensive warranty, ensuring peace of mind for users. It is part of BACHMANN’s extensive line of industrial automation products, offering seamless integration and compatibility with a wide range of control systems.
