Allen-Bradley 1756-IF6I ControlLogix 6-Point Isolated AI Module, Precision Data Acquisition for Industrial Automation
The Allen-Bradley 1756-IF6I is an advanced ControlLogix analog input module designed for precise measurement and monitoring of industrial processes. This 6-point, isolated module ensures reliable data acquisition in harsh environments.
Detailed content
Model Type:Analog Input Module
Manufacturer:Allen-Bradley
Module Number:1756-IF6I
Isolation Type:Optocoupler
Channels:6
Signal Range:-20 to +60 VDC
Accuracy:±0.25% of full scale
Sampling Rate:Up to 1 kHz
Communication Interface:ControlLogix Compatible
Power Consumption:≤ 3.5 mA @ 24 VDC
Enclosure:Open Type
Environmental Conditions:Operating Temp: 0°C to 55°C, Storage Temp: -40°C to 85°C
The AB 1756-IF6I ControlLogix 6-Point Isolated AI Module is a high-performance solution for industrial control systems, designed to offer unparalleled precision and reliability in analog signal acquisition.
Featuring fully isolated channels, this module ensures signal integrity in harsh industrial environments, minimizing interference and ensuring accurate data transmission.
With a wide input range from 4 to 20 mA or 0 to 5 VDC, the 1756-IF6I is compatible with a variety of sensors, making it suitable for a broad range of industrial applications.
Equipped with advanced sampling technology, this module can capture data at frequencies up to 500 Hz, providing real-time feedback for critical process monitoring and control.
Utilizing the robust ControlNet communication protocol, the 1756-IF6I facilitates seamless integration with other industrial components, enhancing system efficiency and productivity.
