Model Type:Scanner Module

Manufacturer:Allen Bradley

Model Number:1756-DNB/E

Communication Protocol:DeviceNet

Amperage Rating:Drawn: 400 MA at 5.1 V

Mounting:Chassis

Enclosure Type:Open

RfI Suppression:[“Radiated: 10 V/M with 1 KHZ Sine-Wave 80% AM from 80 – 2000 MHz”,”10 V/M with 200 Hz 50% Pulse 100% AM at 900 MHz”,”10 V/M with 200 Hz 50% Pulse 100% AM at 1890 MHz”,”3 V/M with 1 KHZ Sine-Wave 80% AM from 2000 – 2700 MHz”,”Conducted: 10 VRMS with 1 KHZ Sine-Wave 80% AM from 150 KHZ – 80 MHz”]

Temperature Range:Not specified

    The Allen Bradley AB 1756-DNB/E ControlLogix DeviceNet Scanner Module is a cornerstone of advanced industrial automation, facilitating smooth communication across diverse devices. It leverages DeviceNet protocol to ensure compatibility and efficiency in complex production environments.

    This scanner module is specifically engineered to handle high data throughput, ensuring that every component within the system operates cohesively. Its robust design withstands harsh industrial conditions, maintaining reliability under demanding circumstances.

    Key to its performance is the efficient management of electrical signals, with a maximum drawn amperage of 400 mA at 5.1 V, ensuring that power consumption is optimized without compromising on functionality. The chassis mounting option provides flexibility in installation, catering to varied industrial settings.

    The open type enclosure ensures easy access for maintenance and upgrades, while the RFI suppression measures protect against interference, safeguarding data integrity and system stability. This feature is particularly crucial in environments prone to electromagnetic noise.

    Despite its advanced capabilities, the Allen Bradley AB 1756-DNB/E ControlLogix DeviceNet Scanner Module is designed with ease of use in mind. Its intuitive interface simplifies configuration and diagnostics, allowing technicians to quickly identify and address issues, enhancing overall productivity.
