Brand:Agilent

Model:HP 5517B

Series:HP-5517B

Serial Number:HP-5517B

Frequency Range:Up to 500 MHz

Sampling Rate:1 GSa/s

Channel Count:2 Channels

Input Impedance:1 MΩ ± 1% parallel 20 pF

Vertical Resolution:8 bits

Display Size:7 inches

Memory Depth:10,000 points per channel

Waveform Capture Rate:1,000 wfm/s

Interface:RS-232, GPIB, USB

    The Agilent HP 5517B Oscilloscope is designed for precision and reliability in industrial applications. With a frequency range up to 500 MHz, this oscilloscope can accurately measure high-frequency signals, ensuring reliable data acquisition. The 1 GSa/s sampling rate provides high-resolution waveform captures, allowing for detailed analysis of transient signals. Equipped with 2 channels, it is versatile enough for a wide range of testing scenarios. Its 7-inch display presents clear and legible waveforms, enhancing user experience. With a memory depth of 10,000 points per channel, the oscilloscope retains detailed waveform data for thorough post-analysis. The 1,000 wfm/s waveform capture rate ensures minimal dead time between acquisitions, maximizing efficiency. For connectivity, the oscilloscope supports RS-232, GPIB, and USB interfaces, facilitating seamless integration into existing systems. Crafted from high-quality materials, the Agilent HP 5517B is built to withstand the rigors of industrial environments, ensuring long-term reliability and performance. This oscilloscope is ideal for engineers and technicians requiring precise and dependable signal analysis tools.
