Technical Specifications
Processor: Equipped with a 32-bit RISC processor with a clock speed up to 200 MHz, ensuring efficient processing capabilities.
I/O Points: Supports up to 256 I/O points, allowing for extensive data input and output operations.
Communication Interfaces: Features a range of communication interfaces including RS232, RS485, Ethernet, and possibly Modbus, enabling seamless integration with other devices and systems.
Power Supply: Operates on 24V DC, ensuring compatibility with standard industrial power supplies.
Power Consumption: Approximately 20W, indicating energy-efficient operation.
Operating Temperature: Designed to operate within a temperature range of -25°C to +70°C, ensuring reliability in various environmental conditions.
Storage Temperature: Can be stored within a range of -40°C to +85°C.
Protection Rating: IP67, indicating a high level of protection against dust and water ingress.
Physical Dimensions: Approximately 225 mm x 165 mm x 80 mm, with a weight of around 2.5 kg, making it a compact and portable solution.
Functional Characteristics
High-Performance Data Acquisition: Capable of real-time data acquisition and processing, supporting a wide range of sensor types including analog, digital, and frequency inputs.
Precision Measurement and Monitoring: Provides precise measurement and monitoring of electrical parameters such as voltage, current, frequency, and temperature, enabling accurate system diagnostics.
Programmable Features: Offers flexibility through programmable parameters and function customization, allowing users to tailor the module to specific application requirements.
Communication Capabilities: Enables seamless data exchange and communication with other devices or systems, facilitating system integration and remote monitoring.
Reliability and Stability: Designed for industrial environments, it exhibits high reliability and stability, ensuring uninterrupted operation even under harsh conditions.
Safety Features: Incorporates safety functions such as data encryption and user permission management, safeguarding data and system security.
Application Scenarios
Power Industry: Used in power plants, substations, and other electricity generation and distribution facilities to provide excitation current for synchronous generators, including steam turbines, water turbines, and wind turbines, ensuring stable power output.
Industrial Automation: Deployed in various industries such as steel, metallurgy, chemicals, and textiles, providing excitation current for industrial machinery like rolling mills, furnaces, compressors, pumps, and textile machines, enabling efficient operation.
Marine Applications: Employed in shipboard power systems, providing excitation current for shipboard generators and propulsion motors, ensuring reliable power supply for navigation and propulsion.
Rail Transportation: Utilized in railway systems, including locomotives and subway trains, to supply excitation current for traction motors, enhancing the performance and reliability of the transportation network.
