Technical Specifications
Type: 16 channel 50V compact module termination unit (MTU)
Compatibility: For S800 I/O modules
Power Supply: DC(9-36)V wide power input with dual power redundancy and isolation protection
Communication:
Supports logic independent dual Profibus DP bus
12 Profibus DP electrical ports and 12 155M optical fiber interfaces
Supports fiber ring network topology for redundant dual networks
Optical fiber distance up to 20km at 155Mb/s for high-speed and long-distance reliable transmission
Protection:
IP30 protection rating
Electrical and ground isolation
Lightning protection up to 4000V on electrical interfaces
Overcurrent protection of 1.5A and surge protection of 600W
Indicators: 6 bicolor LED status indicators for monitoring
Installation: 35mm DIN rail mounting
Material: Wave-pattern aluminum reinforced enclosure
Functional Characteristics
Passive Unit: TU810V1 is a passive unit used for connecting field wiring to I/O modules.
ModuleBus Distribution: Distributes the ModuleBus to I/O modules and the next MTU, ensuring seamless communication.
Address Generation: Generates the correct address for I/O modules by shifting outgoing position signals to the next MTU.
Configuration Flexibility: Two mechanical keys are used for configuring the MTU for different types of I/O modules, offering a total of 36 different configurations.
Signal Isolation and Conversion: Provides electrical isolation to prevent interference propagation and may perform signal conversion to adapt to system requirements.
High Reliability: Designed for industrial environments, ensuring stable operation and long lifespan.
Compact Design: Suitable for installation in limited spaces, enhancing flexibility in industrial control systems.
Application Scenarios
ABB TU810V1 is widely applicable in various industries and automation systems, including but not limited to:
Manufacturing: For connecting sensors, actuators, and other devices in manufacturing lines for process monitoring and control.
Process Industries: Used in chemical, petrochemical, oil and gas, power, and water treatment industries for monitoring and controlling critical processes.
Automation Systems: Integrates seamlessly with ABB automation systems, expanding the I/O capacity of industrial control systems.
Field Devices: Connects field devices such as sensors, actuators, and valves for real-time data acquisition and control.
Infrastructure: Applicable in infrastructure projects such as power distribution, water supply, and sewage treatment.
