Physical Dimensions:
Length: 170mm or 279.4mm
Width: 105mm
Height: 32mm or 360.68mm
Weight: Approximately 120g or 0kg
Operating Temperature: -20°C to +50°C
Storage Temperature: -40°C to +70°C
Humidity: 5% to 95% relative humidity
CPU: 32-bit RISC processor
Functional Characteristics :
Output Channels: Typically equipped with multiple digital output channels, allowing control of multiple external devices or actuators. Some sources mention 16 digital output channels (DO) with open-collector type.
Output Types: Provides digital switching output signals, such as switch signals or pulse signals, for controlling the state or executing specific actions of connected external devices.
Communication Interfaces: Connects to control systems via specific communication interfaces (e.g., Ethernet, RS-485) to receive control commands and send status information.
Diagnostic Capabilities: Some models may feature diagnostic functions to monitor module status and report any faults or abnormalities.
Protection Level: Designed with certain levels of protection against water and dust, suited for various working environments.
Application Scenarios:
Industrial Automation: Commonly used in industrial control systems for automated processes, such as manufacturing lines and process control.
External Device Control: Converts digital signals into control signals for devices like switches, valves, and motors.
System Integration: Serves as an integral part of control units, working alongside other subsystems and I/O modules to achieve seamless system integration and automation.
Specific Systems: Can be found in systems like Symphony Plus I/O HR series (Harmony Rack), where it functions as a subsystem component within the Harmony Control Unit (HCU).
