Technical Specifications
| Specification | Value |
|---|---|
| Input Voltage | 380-500 V AC |
| Output Voltage | 560 V DC |
| Input Current | 300 A peak |
| Output Current | 200 A continuous |
| Output Power | 112 kW |
| Efficiency | >95% |
| Operating Temp. | -10°C to +40°C (14°F to 104°F) |
| Protection Rating | IP20 |
| Dimensions | 310 mm x 250 mm x 140 mm (12.20 in x 9.84 in x 5.51 in) |
| Weight | 10 kg (22.05 lb) |
Functional Features
- High Power Conversion: The PDD200A101 efficiently converts AC input voltage into a stable DC output voltage, providing high-power output capabilities suitable for demanding industrial applications.
- Compact and Rugged Design: Its compact size and rugged construction make it easy to install and suitable for use in harsh industrial environments.
- High Efficiency: With an efficiency rating of over 95%, it minimizes energy loss and heat generation, reducing operating costs and improving system reliability.
- Wide Operating Temperature Range: Capable of operating within a wide temperature range, it ensures reliable performance in various environmental conditions.
- Protection Features: May include overload and short-circuit protection to safeguard the module and connected equipment from damage.
- Compatibility: Designed specifically for ABB AC drive systems, it ensures seamless integration and compatibility with other ABB automation components.
Application Scenarios
ABB PDD200A101 is typically used in the following application scenarios:
- AC Drive Power Supply: Serves as a reliable power source for ABB AC drives, ensuring stable and efficient motor operation.
- Industrial Automation Systems: Integrated into larger industrial automation systems, it enhances the overall functionality and performance of the system.
- Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC): As a module component, it can be used in DCS and PLC systems to extend their capabilities and control complex industrial processes.
- Heavy-Duty Machinery: Powers high-power motors and drives in heavy-duty machinery, such as large conveyor belts, cranes, and other industrial equipment.
