ABB NAIO-03 ANALOGUE IO EXTENSION – Advanced Modular PLC Component for Enhanced Process Control
The ABB NAIO-03 ANALOGUE IO EXTENSION Module is a sophisticated addition to ABB’s PLC family, designed to extend the functionality of programmable logic controllers in industrial automation systems, providing unparalleled precision and reliability in managing complex control tasks.
Detailed content
Model:NAIO-03
Type:Analog Input/Output Extension Board
Brand:ABB
Weight:0.45 kg
Dimensions (WxHxD):120 x 96 x 35 mm
Operating Voltage:24 V DC
Input Current:30 mA max per channel
Output Current:20 mA max per channel
Relay Contacts:30 V AC/DC, 0.5 A max per channel
Operating Temperature:-20°C to +70°C
Storage Temperature:-40°C to +85°C
Compliance Standards:IEC 61131-3, CE, UL, CSA
The ABB NAIO-03 Analogue IO Extension is engineered for seamless integration into industrial automation systems, providing a robust and reliable interface between sensors and actuators.
Featuring a wide operating voltage range and high current capacity, this extension ensures compatibility with various devices, enhancing system flexibility and performance.
Equipped with MODBUS RTU communication protocol, it facilitates easy data exchange with other ABB components and third-party systems, streamlining integration and setup processes.
Designed for operation in harsh industrial environments, the NAIO-03 offers IP20 protection, safeguarding against non-hazardous dust ingress, ensuring durability and reliability.
With its compact size and efficient design, this extension optimizes space utilization on control panels while delivering high-performance data acquisition and control functions.
Ideal for applications requiring precise control and monitoring, the ABB NAIO-03 Analogue IO Extension supports diverse industrial processes, from manufacturing to process control, ensuring enhanced productivity and efficiency.
