ABB LTC391AE01 HIEE401782R0001
1、 Technical specifications
Interface configuration: Built in four independent Ethernet interfaces and an integrated network switch. Two of these interfaces are programmable and support multiple Ethernet based protocols, such as Ethernet and Profinet, allowing PLCs to connect and control two different types of networks.
Connection standard: Following SMARC standards, using sturdy and vibration resistant 314 pin MXM connectors, providing extended operating temperatures from -40 ° C to+85 ° C.
Data transmission rate: With a high data transmission rate, it meets the real-time requirements of industrial applications.
Detailed content
2、 Functional characteristics
Multifunctional Connection: As the core of the new mechanical controller design, LTC391AE01 HIEE401782R0001 can be used in both legacy systems and modern networks, while providing a software architecture that can handle future needs.
Automatic configuration and discovery: Supports automatic discovery of devices on serial cards and PKTX cards, and has the ability to automatically configure devices, simplifying system deployment and maintenance processes.
Digital control function: With strong digital control function, it can meet the needs of complex industrial control scenarios.
Self diagnostic function: Equipped with built-in self diagnostic function, it can timely detect and report equipment failures, improving the reliability and stability of the system.
Scalability and Upgradability: As a building block, LTC391AE01 HIEE401782R0001 allows for effective development and future upgrade paths compatible with the next generation SMARC COM.
3、 Application scenarios
Industrial automation: In the field of industrial automation, LTC391AE01 HIEE401782R0001 can be used for various industrial automation equipment and production lines, achieving precise control and data exchange of equipment.
Power Station Control System: In the power station electrical control system, LTC391AE01 HIEE401782R0001 can be used to build an efficient power station EFCS (Electrical Field Control System), achieving functions such as control, interlocking, measurement, and protection of electrical equipment.
Industrial network communication: As an integrated network switch, LTC391AE01 HIEE401782R0001 can support multiple industrial network communication protocols, achieving seamless connection and data exchange between devices.
