1、 Technical specifications
Processor support: The LDMTR-01 module supports Intel Atom E620T, E640T, E660T, and E680T processors. These processors use 45 nanometer processing technology and have integrated system memory and graphics processing capabilities, providing excellent performance.
Graphics processing capability: Built in Intel Graphics Media Accelerator (GMA) 600 graphics engine, supporting ultra-low power 3D graphics, and equipped with high-definition hardware video decoder and encoder engine, providing perfect imaging capabilities up to 400MHz graphics.
Display interface: Provides LVDS and SDVO graphics interfaces, supporting dual independent displays with resolutions up to 1280×768 @ 60Hz and 1280×1024 @ 85Hz, respectively.
Expansion interfaces: including Gigabit Ethernet LAN controllers, 2 serial ATA 2.0 ports with speeds up to 3GB/s, 7 USB 2.0 host controllers, 1 USB 2.0 host/client, high-definition audio, 3 PCIe x1 interfaces, 1 CAN bus, and 1 SDIO/MMC interface, to meet various expansion needs.
2、 Functional characteristics
High performance processor: Equipped with Intel Atom series processors, it provides powerful computing and graphics processing capabilities, suitable for complex data processing and graphics display tasks.
Hyperthreading Technology: Supports Intel Hyperthreading Technology, allowing each processor core to process two instruction threads simultaneously, improving processor utilization and overall performance.
Low power design: By adopting advanced processor technology and optimized circuit design, low-power operation is achieved, reducing energy consumption and operating costs.
Rich extension interfaces: Provides multiple extension interfaces to facilitate users to configure and expand according to actual needs, meeting the needs of various industrial applications.
Accurate and stable results: Through optimized design and testing, we ensure that accurate and stable results can be provided under various conditions, ensuring the reliability and stability of industrial applications.
Remote monitoring and alarm function: Supports remote monitoring and alarm function, which can transmit real-time device status and fault information, making it convenient for users to remotely manage and maintain.
3、 Application scenarios
The ABB LDMTR-01 embedded processor module is widely used in industrial automation, control systems, intelligent manufacturing and other fields. Specific application scenarios include but are not limited to:
Industrial automation production line: As the core control unit of the production line, it is responsible for data acquisition, processing, and transmission, achieving automation control and optimization of the production line.
Control system integration: As an important component of the control system, it integrates with other devices and modules to achieve complex control logic and data processing tasks.
Intelligent Manufacturing: In the field of intelligent manufacturing, the LDMTR-01 module can be used to control, monitor, and analyze intelligent devices, improving production efficiency and product quality.
