1、 Technical specifications
Power supply voltage: 24 V DC (+-20%)
Dimensions: 47 x 131 x 111 mm (length x height x width)
Weight: approximately 0.4 kg
Installation method: Installed on a 35 mm DIN rail (DIN EN 50 022)
Communication capability: For systems after 800xA SV5.1, signal transmission between HSE and H1 can process up to 160 signals per second between all four H1 links and HSE network, while 4 * 16 client/server connections can be used in parallel.
2、 Functional characteristics
Efficient and reliable communication: LD800HSE 3BDH000320R0101 aims to achieve efficient and reliable communication in industrial environments, supporting seamless connections and data exchange between various devices and systems.
High speed Ethernet function: With its high-speed Ethernet function, it allows for fast and reliable data transmission, ensuring real-time communication between different components of industrial networks.
Protocol Compatibility: Compatible with Ethernet/IP protocol, this is a widely used protocol in industrial automation that can seamlessly integrate with other devices and systems that support Ethernet/IP, achieving efficient data exchange and system integration.
Advanced diagnostic and monitoring functions: providing real-time status information and performance data, allowing for proactive maintenance and troubleshooting, helping to minimize downtime and optimize the overall performance of industrial networks.
Easy to install and configure: With a user-friendly interface and support for various configuration options, it allows seamless integration into existing industrial networks.
Powerful security features: Equipped with powerful security features to prevent unauthorized access and ensure data integrity.
Redundant design: Suitable for redundant use, where the corresponding H1 ports of two linked devices are connected to one H1 link. The independent redundant link between the main link device and the auxiliary link device ensures reliable fault transfer and redundant monitoring.
3、 Application scenarios
LD800HSE 3BDH000320R0101 has a wide range of application scenarios, providing efficient data exchange and system integration, whether it is device connections within a single factory or across multiple locations. This module is particularly suitable for demanding industrial applications such as automated production lines, process control systems, intelligent manufacturing, etc., and can significantly improve production efficiency and system stability.
