ABB FS300R12KE3/AGDR-72C
ABB FS300R12KE3/AGDR-72C is a high-performance Insulated Gate Bipolar Transistor (IGBT) module manufactured by Infineon Technologies under the ABB brand. This module is specifically designed for high-power applications, offering exceptional efficiency and reliability.
Detailed content
Technical Specifications:
Manufacturer: Infineon Technologies (under ABB brand)
Model Number: FS300R12KE3/AGDR-72C
Type: IGBT Module
Voltage Rating: Up to 1200V
Continuous Current Rating: 300A
High Switching Frequency: Enables reduced filter size and cost, improving system efficiency
Low Conduction Losses: Low on-state voltage drop minimizes energy loss during conduction
Optimized Thermal Management: Effective heat dissipation solution ensures reliable performance under high load conditions
Integrated Driver Circuit: Simplifies external drive requirements, reducing design complexity and cost
Protection Features: Includes overcurrent protection and undervoltage lockout (UVLO) for enhanced safety
Physical Dimensions: Approximately 10mm x 20mm x 50mm (as per some sources, dimensions may vary)
Weight: 2kg (as per some sources, weight may vary)
Operating Temperature Range: Depending on the application and cooling system, typical ranges apply
Environmental Conditions: Suitable for use in industrial environments with specified temperature and humidity limits
Functional Characteristics:
High Power Density: Capable of handling large power loads, making it ideal for demanding applications.
Efficiency: High switching frequency and low conduction losses contribute to overall system efficiency.
Ease of Integration: Modular design facilitates quick installation and maintenance, as well as seamless integration into existing systems.
Global Support: As part of Infineon’s product line, FS300R12KE3/AGDR-72C benefits from the company’s extensive global service and support network.
Application Scenarios:
Electric Vehicle Charging Stations: Utilized in high-power charging infrastructure for electric vehicles.
Renewable Energy Systems: Found in solar inverters and other renewable energy conversion systems.
Industrial and Commercial Inverters: Widely used in industrial and commercial motor drives, AC/DC converters, and other power conversion equipment.
Demanding Industrial Environments: Suitable for applications requiring high power density, efficiency, and reliability, such as heavy machinery, automation systems, and process control.
