ABB DSQC503 3HAC18159-1/03 Touch Panel – Human Machine Interface, Advanced Control Solutions
The ABB DSQC503 3HAC18159-1/03 Touch Panel is a high-performance HMI solution designed for industrial automation systems. It provides intuitive graphical user interfaces and seamless integration capabilities, enhancing operational efficiency.
Detailed content
Dimensions (WxHxD):297.18mm x 35.56mm x 175.26mm
Weight:0.6kg
Operating Temperature Range:-20°C to +60°C
Power Consumption:Less than 5W
Touch Technology:Capacitive
Connectivity:RS-232, RS-485, Ethernet
Screen Resolution:800×600 pixels
Memory:8MB Flash, 2MB SDRAM
Operating System:RTOS
Experience unparalleled ease-of-use and efficiency with the ABB DSQC503 3HAC18159-1/03 Touch Panel, designed specifically for demanding industrial environments. This touch panel is equipped with a capacitive screen offering high-resolution visuals for superior clarity and detail.
Engineered for robust performance, it operates within a wide temperature range (-20°C to +60°C), ensuring reliable functionality regardless of environmental conditions. The compact size and lightweight design make it ideal for space-constrained installations.
Featuring advanced connectivity options including RS-232, RS-485, and Ethernet, the DSQC503 facilitates seamless integration with various control systems, enabling smooth data exchange and process monitoring.
Equipped with 8MB Flash and 2MB SDRAM, this touch panel boasts ample storage and fast processing capabilities, supporting a range of applications from simple to complex. The Real-Time Operating System (RTOS) ensures efficient multitasking and responsive operation.
Innovative and intuitive, the ABB DSQC503 3HAC18159-1/03 Touch Panel streamlines operator interaction, enhancing productivity and reducing errors in your industrial processes. It is an indispensable tool for modern automation and control systems.
