ABB 3HAC14549-3/09A Rectifier Module for Industrial Control Systems
The ABB 3HAC14549-3/09A Rectifier Module is a high-performance component designed for use in industrial control systems. It is renowned for its reliability and efficiency in converting AC power to DC, making it ideal for various industrial applications requiring precise control and power management.
Detailed content
Operating Voltage:690 V AC
Output Frequency:50 Hz
Input Current:Up to 1600 A
Output Power:Up to 1600 kW
Efficiency Rating:≥ 98%
Cooling Method:Water-cooled
Weight:Approximately 100 kg
Dimensions (WxHxD):1000 x 800 x 400 mm
Environmental Conditions:Operating temperature range from -10°C to +40°C
Certifications:[“CE”,”UL”]
The ABB 3HAC14549-3/09A Rectifier Module is a state-of-the-art solution for industrial automation systems, featuring advanced semiconductor technology for superior performance and reliability.
Engineered for durability, this module operates efficiently under various environmental conditions, ensuring continuous and stable power delivery.
It supports a wide input voltage range, making it adaptable for diverse industrial settings and applications. Its adjustable output voltage allows for customization to meet specific system requirements.
With an efficiency rating of ≥95%, the ABB 3HAC14549-3/09A Rectifier Module ensures minimal energy loss during power conversion, contributing to cost-effective and eco-friendly operation.
For ease of integration, this rectifier module comes with standard mounting holes and connectors compatible with industry-standard cables, facilitating quick setup and maintenance.
