Screen size: Although it is not an operating panel itself, as part of the system, it may be used in conjunction with operating panels ranging from 7 inches to 15 inches, which have full-color screens and high-resolution display capabilities.
Communication interface: Supports various communication ports such as RS232, RS422, RS485, Ethernet, as well as USB ports, making it convenient to connect with various controllers, devices, sensors, motors, cameras, etc.
Power parameters: Input voltage range 12-48VDC, output voltage range 5VDC, maximum output current 10A, efficiency greater than 90%.
Physical dimensions: approximately 170mm x 105mm x 32mm, weight approximately 120g, convenient for installation and integration.
Functional characteristics
Signal processing capability:
Signal amplification: capable of amplifying input signals, increasing their amplitude and strength.
Signal filtering: The signal is filtered through a filter to remove noise and interference components, while retaining useful signals.
Signal conversion: converting input signals into other forms or formats of signals to meet different system and device requirements.
Signal regulation: Adjusting the frequency, phase, amplitude and other parameters of a signal to meet specific signal processing requirements.
Analog to Digital Signal Conversion: Analog signals can be converted into digital signals, or digital signals can be converted back to analog signals, which is particularly important in industrial applications.
Multiple input types and powerful output capabilities: Supports multiple input types such as voltage, current, and digital signals, and digital outputs can switch loads up to 2A.
Flexible communication protocols: Supports multiple communication protocols such as Modbus, Profibus, etc., facilitating data exchange and integration with other devices.
Rich software support: Provides open platform flexibility for the WinCE R6 operating system GX6 series, which can work perfectly with third-party software engines. It supports automatic adjustment of text and image sizes based on object size, grouping multiple objects to move, adjust size, and modify their common properties, rotating images or changing their color tones, etc.
Application scenarios
ABB 129740-002 is widely used in the field of industrial automation, especially in process control, manufacturing, and automation. It can be used as part of a PLC (Programmable Logic Controller) system for monitoring and controlling various industrial processes. By integrating with other sensors, actuators, and control systems, precise data acquisition, processing, and control can be achieved.
