AB 2711P-K4M20D Graphic Operator Terminal – Advanced Control Solutions
The ABB AB 2711P-K4M20D Graphic Operator Terminal is a high-definition, 10-inch touchscreen display designed for industrial control systems. It provides an intuitive interface for operators to monitor and control complex machinery in manufacturing and automation processes.
Detailed content
Display Size:10.4 inches
Resolution:640×480 pixels
Memory Capacity:5MB
Color Depth:16 colors
Operating Voltage:24VDC
Communication Interface:RS-232, RS-485, Ethernet
Touchscreen Technology:Finger-proof, capacitive touch
Dimensions:33 cm x 17.8 cm x 5.5 cm
Weight:1.42 kg
Operating Temperature:-10°C to +50°C
Storage Temperature:-20°C to +70°C
The AB 2711P-K4M20D Graphic Operator Terminal is equipped with a high-resolution, 10.4-inch TFT display, providing clear visual feedback for enhanced operational oversight. Its capacitive touchscreen ensures smooth and responsive user interactions, even with gloves or light fingers.
With support for multiple communication interfaces, including RS-232, RS-485, and Ethernet, this terminal facilitates easy connectivity with a variety of industrial devices and systems, ensuring seamless data exchange and control over automation processes.
Featuring an advanced memory system with 5MB capacity, the terminal can store extensive data logs and application configurations, enabling users to monitor historical data trends and make informed decisions based on past performance.
Engineered for robust performance in diverse environmental conditions, the AB 2711P-K4M20D is designed to withstand temperatures ranging from -10°C to +50°C during operation and -20°C to +70°C during storage, making it suitable for installation in challenging industrial settings.
Incorporating ergonomic design principles, this operator terminal ensures comfort and ease of use for extended periods. Its compact size and lightweight construction facilitate efficient installation and integration into various industrial control panels.
